EXPLODED VIEW AND PARTS LIST
No. Part Number Part Description
1-8 6377-015A Gearbox Assembly
9 6377-009 Locking Shaft
10 6377-015A Gearbox Assembly
11-14 6377-012A Dust Collection Assembly
15 6377-015A Gear Box
16-32 6377-031A Motor Assembly
33 6377-033 Carbon Brush (Set of 2)
34-38 6377-031A Motor Assembly
39 6377-039 Screw M6 x 14
40 6377-041A Circular Head Assembly
41 6377-041 Circular Sanding Pad
42-46 6377-041A Circular Head Assembly
47 6377-047 Screw M4x12
48-67 6377-041A Circular Head Assembly
67A 6377-067A Shaft Cap
68 6377-041A Circular Head Assembly
69 6377-080A Triangular Head Assembly
70 6377-070 Traingular Sanding Pad
71-109 6377-080A Triangular Head Assembly
110 6369-054 Tightening Ring 25-38
111 6369-055 350 Hose
112 6369-056 Small Cable Sleeve
113 6369-057 Small Rubber Cover
114 6369-058 Right Handle Stand
115 6369-046 Screw M4x14
116 6369-059 Ø28 Connector
117 6369-060 Plastic Soft Pipe Ø28
118 6369-061 Ellipticle Connector
119 6369-062 Left Handle Stand
121 6369-066 Cable Plate
123 6369-068 Electronic Speed Control Plate
124 6369-069 Potentiometer
125 6369-070 Speed Button
126 6377-163 Inner Wire
127 6369-071 Cable
128 6369-072 Cable Sleeve
129 6369-073 Left Main Handle
No. Part Number Part Description
130 6369-074 Aluminum Pipe Insert
131 6369-075 Cable Pressing Plate
132 6369-076 Left Sub-Handle
133 6369-077 Aluminum Pipe
134 6369-078 Back Hinge Sleeve
135 6369-079 Ø5x45 Pin
136 6369-080 Ø5 Clinch Bolt
137 6369-081 Ø1.2 Sealed Ring
138 6369-082 Front Hinge Sleeve
139 6369-083 Aluminum Pipe
140 6369-087 Sleeve 2#
141 6369-088 Front Latch
142 6369-089 Spring
143 6369-090 Latch Pivot
144 6369-091 Fixed Plate
145 6369-084 Supporting Arm
146 6369-085 Ø5x30 Pin
147 6369-086 Ø5x16.8 Pin
148 6369-092 Aluminum Pipe With Single Access
149 6369-093 Switch
150 6369-094 Switch Pushing Lever
151 6369-095 Switch Button
152 6369-096 Right Sub-Handle
153 6369-097 Circular Pin Ø1.5x11.8
154 6369-098 Back Screw Nut
155 6369-099 Right Main Handle
156 6369-100 Hose Connection Adapter
157 6369-101 Adjustable Ring
158 6377-158 Buckle
159 6377-159 Copper Strips
160 6377-160 3 Tooth Buckle
161 6377-161 Y Buckle
162 6377-162 Heat Shrink Tubing
163 6377-163 Inner Wire
164 6369-102 Connection Adapter
166 6369-103 Dust Tube
167 6377-167 Wrench
