KNOW YOUR BELT & DISC SANDER
TOOL PURPOSE
Sand, smooth, and remove jagged edges with your WEN Belt and Disc Sander. Refer to the following diagrams to
become familiarized with all the parts and controls of your belt and disc sander. The components will be referred to
later in the manual for assembly and operation instructions.
Sanding Belt
Table Angle
Adjustment Knob
Dust Port
Work Support
Belt Tension Lever
Tracking Control Knob
Miter Gauge
Work Table
Sanding Disc Power Switch
Base Bolt Holes
