EXPLODED VIEW AND PARTS LIST
No. Part Number Part Description Qty
1 6560-001 Hex Nut 1
2 6560-002 Block 1
3 6560-003 Shaft 1
4 6560-004 Spring 1
5 6560-005 Fence Lock 1
6 6560-006 Socket Head Screw 1
7 6560-007 Fence Bracket 1
8 6560-008 Hex Nut 1
9 6560-009 Bracket Shaft 1
10 6560-010 Lock Washer 4
11 6560-011 Socket Head Screw 4
12 6560-012 Push Nut 2
13 6560-013 Right Linkage 1
14 6560-014 Spacer 1
15 6560-015 Fence Tilting Handle 1
16 6560-016 Fence Plate Shaft 1
17 6560-017 Socket Head Screw 4
18 6560-018 Lock Washer 4
19 6560-019 Fence Plate 1
20 6560-020 Hex Head Bolt 1
21 6560-021 Hex Nut 1
22 6560-022 Fence 1
23 6560-023 Left Linkage 1
24 6560-024 Hex Head Bolt 1
25 6560-025 Hex Nut 1
26 6560-026 Fence Sliding Handle 1
27 6560-027 Spacer 1
28 6560-028 Socket Head Screw 2
29 6560-029 Lock Washer 2
30 6560-030 Fence Support 1
31 6560-031 Pin 2
32 6560-032 Locking Plate 1
33 6560-033 Hex Nut 1
34 6560-034 Hex Head Bolt 1
35 6560-035 E Ring 4
36 6560-036 Table Frame 1
37 6560-037 Infeed Table 1
38 6560-038 Bracket 4
39 6560-039 Table Pin 4
40 6560-040 Frame Pin 4
41 6560-041 Set Screw 1
42 6560-042 Hex Nut 1
No. Part Number Part Description Qty
43 6560-043 Ball Bearing 2
44 6560-044 Retaining Ring 1
45 6560-045 Set Screw 1
46 6560-046 Hex Nut 1
47 6560-047 Support Plate 1
48 6560-048 Lock Washer 2
49 6560-049 Socket Head Screw 2
50 6560-050 Height Adjustment Screw 1
51 6560-051 Height Adjustment Knob 1
52 6560-052 Flat Washer 1
53 6560-053 Pan Head Screw 1
54 6560-054 Serriated Washer 2
55 6560-055 Pan Head Screw 2
56 6560-056 Main Body w/ Outfeed Table 1
57 6560-057 Set Screw 4
58 6560-058 Flat Washer 4
59 6560-059 Lock Washer 4
60 6560-060 Socket Head Screw 4
61 6560-061 Brush 2
62 6560-062 Motor 1
63 6560-063 Motor Pulley 1
64 6560-064 Flat Washer 4
65 6560-065 Lock Washer 4
66 6560-066 Socket Head Screw 4
67 6560-067 Motor Support 1
68 6560-068 Lock Washer 4
69 6560-069 Socket Head Screw 4
70 6560-070 Power Cord Clamp 1
71 6560-071 Spring 1
72 6560-072 Pin 1
73 6560-073 Pan Head Screw 1
74 6560-074 Bumper 1
75 6560-075 Blade Guard 1
76 6560-076 Spring 1
77 6560-077 Flat Washer 1
78 6560-078 Socket Head Screw 1
79 6560-079 Drive Belt 1
80 6560-080 Shaft 1
81 6560-081 Screw 8
82 6560-082 Blade Clamp 2
83 6560-083 Blade 2
84 6560-084 Blade Shaft 1
No. Part Number Part Description Qty
85 6560-085 Jack Screw 4
86 6560-086 Set Screw 3
87 6560-087 Set Screw 1
88 6560-088 Drive Pulley 1
89 6560-089 Blade Cover 1
90 6560-090 Socket Head Screw 2
91 6560-091 Fan Belt 1
92 6560-092 Flat Washer 3
93 6560-093 Pan Head Screw 3
94 6560-094 Chip Collector 1
95 6560-095 Chip Exhaust 1
96 6560-096 Dust Port 1
97 6560-097 Pan Head Screw 1
98 6560-098 Socket Head Screw 1
99 6560-099 Flat Washer 1
100 6560-100 Fan 1
101 6560-101 Mounting Plate 1
102 6560-102 Flat Washer 2
103 6560-103 Lock Washer 2
104 6560-104 Socket Head Screw 2
105 6560-105 Fan Shaft 1
106 6560-106 Ball Bearing 2
107 6560-107 Spacer 1
108 6560-108 Set Screw 1
109 6560-109 Fan Pulley 1
110 6560-110 Thread Forming Screw 6
111 6560-111 Base 1
112 6560-112 Switch 1
113 6560-113 Flat Head Screw 13
114 6560-114 Cover 1
115 6560-115 Flat Washer 6
116 6560-116 Pan Head Screw 6
117 6560-117 Foot A 2
118 6560-118 Foot B 2
119 6560-119 Strain Relief 1
120 6560-120 Power Cord 1
121 6560-121 Push Stick 1
122 6560-122 Push Block 1
123 6560-123 Spring 1
124 6560-124 Filter Bag 1
125 6560-125 Connector 3
126 6560-126 Support Segment 3
