UNPACKING
Check to make sure all above items are accounted for before attempting to assemble and operate your jointer.
WARNING: Do not attempt assembly if parts are missing. Use this manual to order replacement parts.
7
KNOW YOUR JOINTER
ASSEMBLY AND ADJUSTMENTS
Infeed Table
Power Switch
Crank Handle
Dust Port
Blade Guard
A - Jointer
B - Fence
C - Fence Tilting Handle with Spacer
D - Fence Bracket Assembly
E - Fence Support
F - Spring
G - Fence Sliding Handle with Spacer
H - Locking Plate Assembly
I - Filter Bag
J - Connector
K - Support Segment
L - Dust Chute
M - Push Block
N - Push Stick
Hardware Bag Includes:
- M8X20 Socket Head Bolts (8)
- 8mm Lock Washer (6)
- 3, 4, 5 and 6 mm Hex Wrench
Outfeed Table
Fence
A
B
C
D
E
F
G
H
I
J
K
L
M
N
