Wen DC3402 User Manual

14
EXPLODED VIEW & PARTS LIST
No. Part No. Description Qty.
1 DC3402-001 Caster 4
2 Lock Nut, M5 16
3
Pan Head Screw,
M5x10
16
4 Washer, 5mm 16
5 Base Plate 1
6
Pan Head Screw,
M5x8
12
7 Inlet Cover 1
8
Socket Head Cap
Screw, M6x20
1
9
Pan Head Screw,
M5x8
1
10 Washer 1
11 Impeller 1
12 Collector Body 1
13 Washer, 8mm 10
14 Nut, M8 4
15 Lock Washer, 8mm 14
16
Hex Head Screw,
M8x12
6
17
Hex Head Screw,
M8x16
4
18
Hex Head Screw,
M6x20
6
19 Nut, M6 6
20 Washer, 6mm 6
No. Part No. Description Qty.
21 3401-035 Switch 1
22 3403-046 Switch Box 1
23 Hose Clamp 1
24 DC3402-024 Motor 1
N.P.
Capacitor, 125V,
200uF
1
25 Spacer 1
26 Motor Mount 1
27 Motor Key, 5x5x25 1
28 DC3402-028 Outlet Gasket 1
29 Outlet 1
30 DC3402-030 Collector Bag 1
31 Handle 1
32 Power Cord 1
33 DC3402-033 Wall Bracket 2
34
Hex Head Screw,
M6x20
2
35 DC3402-035 Inlet Gasket 1
36
Self-Tapping Screw,
ST4x12
2
37
Hex Head Screw,
M8x20
4
38 Washer, 8mm 4
39 Switch Plate 1
40
Hex Head Screw,
M8x16
2
42 DC3402-042 Breaker, 9A 1
NOTE: Not all parts may be available for purchase. Parts and accessories that wear down over the course of
normal use are not covered under the warranty.
