Wen DF500iX - Page 37

NO. PART NO. DESCRIPTION QTY.
1 DF500iX-001 Screw, M5x10 6
2 DF500iX-002
Control Panel
Assembly
1
3 DF500iX-003 Step Bolt, M6x15 24
4 DF500iX-004 Front Cover 1
5 56360iX-108 Wiring Sheath, 25mm 2
6 56202i-051 Bolt, M6x12 8
7 DF480iX-090
LPG Quick-connector
Cap
1
8 DF500iX-008 Front Cover Plug 3
9 DF500iX-009 Engine Assembly 1
10 DF500iX-010
Self-tapping Screw,
ST3.5x13
1
11 DF500iX-011 Washer, 4mm 1
12 DF500iX-012 Igniter 1
13 DF500iX-013
Handle Protection
Plate
1
14 DF500iX-014
Sound Insulation Pad
2
1
15 DF500iX-015
Battery, 12V 7Ah,
Lead-acid
1
16 DF500iX-016 Left Housing 1
17 DF500iX-017 Left Panel Assembly 1
18 DF500iX-018 Nut, M6 6
19 DF500iX-019 Fuel Tank Cap 1
20 DF500iX-020 Fuel Tank Seal 1
21 DF500iX-021 Adjustable Handle 1
22 DF500iX-022 Drawbar Pin 2
23 DF500iX-023
Upper Housing
Assembly
1
24 DF500iX-024
Upper Handle Assem-
bly
1
25 DF500iX-025
Handle Connecting
Bolt
2
26 DF500iX-026 Bolt, M6x25 4
27 DF500iX-027
Washer,
6.5x1.5x25mm
10
28 DF500iX-028 Clamp 1
29 DF500iX-029 Fuel Hose 1
NO. PART NO. DESCRIPTION QTY.
30 DF500iX-030 Spacer 2
31 56477i-026 Clip 3
32 DF500iX-032 Fuel Tank 1
33 DF500iX-033 Inverter 1
34 DF500iX-034 Fuel Hose 1
35 DF500iX-035 Clamp 2
36 DF500iX-078
Display Multimeter
Wiring Harness
1
37 DF500iX-037 Clip 4
38 DF500iX-038 Fuel Hose Jacket 1
39 DF500iX-039 LPG Quick-connector 1
40 DF500iX-040 Rear Cover 1
41 56202i-121 Nut, M6 2
42 DF500iX-042 Rear Cover Gasket 1
43 DF500iX-080
Remote Start Engine
Control Module
1
44 DF480iX-076
Self-tapping Screw,
ST4.2x16
2
45 DF500iX-045 Bolt, M8x16 2
46 DF500iX-046 Stepped Bolt, M6x17 6
47 DF480iX-087
Fuel Hose Clamp,
16mm
1
48 DF500iX-048
Fuel Valve and
Selector Switch
1
49 DF500iX-049 Right Housing 1
50 DF500iX-050
Battery Wiring
Harness
1
51 DF500iX-051 Tape 1
52 DF500iX-052
Sound Insulation Pad
1
2
53 56477i-025 Bolt, M5x12 3
54 DF500iX-054 Right Panel Assembly 1
55 56202i-001 Phillips Screw, M4x10 1
56 DF500iX-056 Engine Mount 1 1
57 DF500iX-057 Engine Mount 2 1
58 DF500iX-058 Engine Mount 3 2
59 DF500iX-059 Nut, M8 10
60 DF500iX-060 Rectifier 1
EXPLODED VIEW & PARTS LIST
GENERATOR
37
