EXPLODED VIEW & PARTS LIST
GENERATOR
NO. PART NO. DESCRIPTION QTY.
61 DF500iX-061 Bottom Bracket 2
62 DF480iX-080 Bolt, M6x16 2
63 DF500iX-063 Charger 1
64 DF500iX-064 Support Frame 1
65 DF500iX-065 Switch Box Base 1
66 56360iX-125 CO Alarm 1
67 DF500iX-067 CO Sensor Cover 1
68 DF500iX-068 Bolt, M4x16 2
69 DF500iX-069 Wheel Shaft Assembly 1
70 56477i-019B Wheel 2
NO. PART NO. DESCRIPTION QTY.
71 56477i-018 Bolt, M8x12 2
72 56477i-046B Foot 4
73 DF500iX-073 Bolt, M6x12 3
74 DF480iX-078 Screw, M2.5x20 2
75 DF480iX-064
LPG Switch Wiring
Harness
1
76 DF480iX-079 Nut, M2.5 2
N.P. DF500iX-079
LPG Regulator and
Hose Assembly
1
