NO. PART NO. DESCRIPTION QTY.
68 DF500iX-168 Grounding Wire 1
69 56360iX-093 Bolt, M6x12 3
70 DF500iX-170 Washer, 12x2x20mm 1
71 DF500iX-171 Oil Drain Tube Assembly 1
72 DF500iX-172 Trigger 1
73 56360iX-055 Oil Seal, 25 x 41.25 x 6 1
74 DF500iX-174 Stator 1
75 DF500iX-175 Bolt, M6x60 4
76 DF500iX-176 Rotor 1
77 56477i-182 Cooling Fan 1
78 DF500iX-178 Starter Cup 1
79 56477i-184 Nut, M14-1.5 1
80 DF500iX-180 Fan Housing 1
81 56360iX-082 Clip 1
82 DF500iX-182 Bolt, M6x55 2
83
DG-
4500iX-193
Bolt, M6x100 1
84 DF500iX-184 Stud, M8x120 2
85 DF500iX-185 Resonant Cavity 1
86 DF500iX-186 Recoil Starter 1
87 DF500iX-187 Bumper Pad 1
88 DF500iX-188
Recoil Starter Shroud,
Lower
1
89 DF500iX-189 Dipstick Assembly 1
90 56477i-133 Bolt, M6x25 1
NO. PART NO. DESCRIPTION QTY.
91 DF500iX-191 Fuel Hose Bracket 1
92 DF500iX-192 Clip Housing 1
93 DF500iX-193
Recoil Starter Shroud,
Upper
1
94 56360iX-087
Self-tapping Screw,
ST4.2x25
6
95 56480iX-196 Bolt, M6x30 2
96 DF500iX-196 Ignition Coil 1
97 DF500iX-197
Self-tapping Screw,
ST4.8x25
2
98 DF500iX-198 Clip Base 1
99 DF500iX-199 Starter Motor 1
100 DF500iX-200 Clamp 1
101 DF500iX-201 Choke Lever Bracket 1
102 DF500iX-202 Fuel Hose Clamp 1
103 DF500iX-203 LPG Hose 1
104 DF500iX-204 Clamp 1
105 DF500iX-205 Washer, φ5 1
106 DF500iX-206 Bumper Pad 1
107 56480iX-109 Screw, M4x8 1
108 56480iX-110 Nut, M4 1
109 DF500iX-209
Self-tapping Screw,
ST4.2x13
2
N.P.
DF500iX-
HA39
High-altitude Kit,
3000 - 9000 ft
1
41
EXPLODED VIEW & PARTS LIST
ENGINE
NOTE: Not all parts may be available for purchase. Parts and accessories that wear
down over the course of normal use are not covered under the warranty.
