Wen DW1085

EXPLODED VIEW & PARTS LIST
No. Part No. Description Qty.
1 6362-001 Hex Screw M6x14 1
2 6362-002 M6 Spring 1
3 6362-003 M6 Stop Button 1
4 DW5062-003 Sanding Pad 1
5 6362-005 Oil Seal 1
6 6362-006 Output Shaft 1
7 6362-007
Collar ɸ22
1
8 6362-008 Bearing 6900 RS 1
9 6362-009 End Cover 1
10 6362-010 Screw ST3.9x16 6
11 6362-011 Paper Washer 1
12 6362-012 Big Gear 1
13 6362-013 Spring 1
14 6362-014 Clamp Plate for Disc 1
15 6362-015 Disc 1
17 6362-017 Brush Segment 1
18 6362-018 Screw ST3x8 1
19 6362-019 Waved Sleeve 1
20 6362-020
Ball ɸ4
1
21 6362-021
Spring of Adjust
Knob
1
22 6362-022 Adjust Knob 1
23 6362-023
Flat Washer ɸ4
1
24 6362-024 Screw ST3.9x10 1
25 6362-025 Spring of Rotor 1
26 6362-026 Wool Washer 1
27 6362-027 Bearing 608RS 1
28 6362-028
Flat Washer ɸ8
1
29 6362-029 Rotor 1
30 6362-030 Stator 1
31 6362-031 Magnet Ring 1
32 6362-032
Flat Washer ɸ7
1
33 6362-033 Bearing 607RS 1
34 6362-034 Speed Regulator 1
No. Part No. Description Qty.
35 6362-035
Pin ɸ3x16
1
36 6362-036
Seal Belt ɸ1.2
1
37 6362-037 Bearing 606Z 1
38 6362-038 Tension Spring 2
39 6362-039 Brush Holder 2
40 6362-040 Carbon Brush 2
41 6362-041 Brush Holder Cover 2
42 6362-042 Switch 1
43 6362-043 Ventilation Board 1
44 6362-044 Housing 1
45 6362-045
Clamp Plate for
Cable
1
46 6362-046 Screw ST3.9x14 8
47 6362-047 Screw ST3x10 1
48 6362-048 Screw ST3.9x16 9
49 6362-049 Cable 1
50 6362-050 Cable Sleeve 1
51 6362-051 Handle 1
52 6362-052 Dust Bag 1
53 6362-053 Dust Tube 1
54 6362-054 Middle Connector 3
55 6362-055 57mm Adapter 2
56 6369-102 47mm Adapter 1
57 6362-057 Dust Port Connector 1
58 6362-058 Hex Wrench M5 1
59 6362-059 Shoulder Strap 1
N.P. DW150SP
150-Grit Sanding
Disc
2
N.P. DW180SP
180-Grit Sanding
Disc
2
N.P. DW240SP
240-Grit Sanding
Disc
2
N.P. DW400SP
400-Grit Sanding
Disc
2
NOTE: Not all parts may be available for purchase. Parts and accessories that wear
down over the course of normal use are not covered under the warranty.
