13
OPERATING THE SANDER
1. Connect the tool to power supply.
2. Hold the sander base in contact with a stable, secure
workpiece (Fig. 5) and flip the ON / OFF switch (Fig. 6 - 1)
to the ON position.
3. Use the speed control dial (Fig. 6 - 2) to adjust the speed
between 1800 RPM and 3200 RPM.
4. When sanding is complete, flip the ON / OFF switch to the
OFF position.
USING THE EDGE GUIDE
1. Begin sanding operation at one end of the workpiece with
the face of the edge guide against the workpiece. The tool
will remove an even amount of material (Fig. 5).
2. Gradually feed sander along the entire edge of the work-
piece (Fig. 5).
OPERATION
WARNING! Do not plug in or turn on the tool until it is fully assembled according to the instructions. Read
through and become familiarized with the following procedures of handling and adjusting your tool. Failure to
follow the safety instructions may result in serious personal injury.
Fig. 6
Fig. 5
1
2
