Technical Data
3. Technical Data
3.1 General Data
Optical Data
Working range 0 … 10,000 mm
Maximum reproducibility 3 mm*
Linearity deviation 10 mm*
Light source Laser (red)
Wavelength 660 nm
Service life (ambient temp. = +25 °C) 100,000 h
Laser class (EN 60825-1) 1
Beam divergence < 2 mrad
Max. permitted ambient light 100,000 lux
Light spot diameter See table 1
Electrical Data
Supply voltage 18 – 30 V DC
Temperature drift < 0,4 mm/K
Temperature range –40 … –50° C
Switching output voltage drop < 2.5 V
Switching output switching current 100 mA
Short-circuit protection Yes
Reverse polarity protected Yes
Overload-proof Yes
Interface IO-Link V1.1
Transmission speed COM3
Protection class III
Mechanical Data
Setting method Teach-in
Housing material Plastic
Optic cover PMMA
Degree of protection IP67/IP68
Depends on mode, see chapter “3.4 Mode-Dependent Data” on page 10
