The wiring list on the following pages contains the wire numbers, colors and types of wires used in the harness GO 1. Beginning and end of each wire are also identified
as to subunit name and terminal designation as far as the wiring of the organ is concerned, we do not make use of this list. It is provided as an aid in trouble-shooting and
for future reference.
Table 1 Wire List of Harness GO 1
Wire Material/Color Starts at: Ends at: Purpose, Remarks
W = stranded
wire
(Subunit, PC Board, Terminal) (Subunit, PC Board, Terminal)
S = shielded
cable
1 W blue Power supply, PS 1, -15V Tone generator, G 1, plug A, pin 8 Neg. supply voltage
2 W blue Power supply, PS 1, -15V Piano, PI 1, plug 3, pin -15V Neg. supply voltage
3 W blue Power supply, PS 1, -15V Keyers, V 1, term. -15 Neg. supply voltage
4 W blue Power supply, PS 1, -15V Wersivoice, WV 7, pin 18 (-15) Neg. supply voltage
5 W blue Power supply, PS 1, -15V Pedal electronics, P E 13, plug 7, pin -15 Neg. supply voltage
6 W blue Power supply, PS 1, -15V Preamp, VV 2, plug 5, pin - 15 Neg. supply voltage
7 W blue Power supply,PS 1, -15V Bus bar L/Man Keying voltage for
envelope control
8 W blue Power supply, PS 1, -15V Program switches, S P 1, point -15
9 W blue Power supply, PS 1, -15V Wah wah control, term. A
10 W blue Power supply, PS 1, -15V Piano, PI 13, point " Neg. supply voltage
11a W blue Power supply, PS 1, -15V Bus bar U/Man Keying voltage for
envelope control
11b W blue Bus bar U /Man Envelope control, H K 13, U /Man, term. -1
5
Neg. supply voltage
12 W blue Power supply, PS 1, -15V A P 1, master pitch control, term. A (start) Neg. supply voltage
13 W blue Power supply, PS 1, -15V Programming, P R 1, plug 2, pin 17 Neg. supply voltage
14 W blue Power supply, PS 1, -15V Spec. effects rate control, term. S (wiper) Neg. supply voltage
15a W blue Power supply, PS 1, -1 5V Spec. effects, E F 1, plug 1, pin 3 N eg. supply voltage
15b W blue Spec. effects, E F 1, plug 1, pin 3 Spec. effects, E F 1, plug 3, pin 24 Neg. supply voltage
AM 071 (Part)
