Wire Material/Color Starts at: Ends at: Purpose, Remarks
W = stranded
wire
(Subunit, PC Board, Terminal) (Subunit, PC Board, Terminal)
S = shielded
cable
16 W blue Power supply, PS 1, -15V Fixed stops U/M an, G P 1, plug 2, pin -15 Neg. supply voltage
17 W blue Power supply, PS 1, -15V Fixed stops L/Man, G P 1, plug 2, pin - 15 Neg. supply voltage
18 not used
19 not used
20 not used
21 W red Power suppIy,PS 1,+15V Tone generator, G 1, plug A, pin 4 Pos.supply voltage
22 W red Power supply, P S 1, +15V Piano, PI 1, plug 3, pin +15 Pos. supply voltage
23 W red Power suppIy,PS1,+15V Keyers,Vl,term.+15 Pos.supplyvoltage
24 W red Power supply, PS 1, +15V Wersivoice, WV 7, pin 11 (+15) Pos.supply voltage
25 W red Power supply, PS 1, +15V Pedal electronics, P E 13, plug 7, pin +15 Pos. su p ply voltage
26 W red Power supply, PS 1, +1 5V Preamp, VV 2, plug 5, pin + 15 Pos.supply voltage
27a W red Power supply, PS 1, +1 5V Piano, PI 13, term. "+" Pos. supply voltage
27b W red Piano, Pll3,term."+" Piano, Pl12,2nd octave, term. "+" Pos.supplyvoltage
27c W red Piano, PI 12, 2nd octave, term. "+ " Piano, PI 12, 3rd octave, term. "+" Pos.supply voltage
27d W red Piano, PI 12, 3rd octave, term. "+ " Piano, PI 12, 4th octave, term. "+" Pos.supply voltage
28 W red Power supply, PS 1,+15V Spec. effects, E F 1, plug 3, pin 19 (+15V) Pos.supply voltage
29 W red Power supply, PS 1, +15V Fixed stops, U/Man, G P 1, plug 2, pin +15 Pos.supply voltage
30 W red Power suppIy,PS 1,+15V Fixed stops, L/M an, G P 1, plug 2, pin +15 Pos.supply voltage
31 not used
32 not used
33 not used
34 not used
35 not used
AM 071 (Part)
