Wire Material/Color Starts at: Ends at: Purpose, Remarks
W = stranded
wire
(Subunit, PC Board, Terminal) (Subunit, PC Board, Terminal)
S = shielded
cable
36 W green Programming, P R 1, plug 2, pin 15 Envelope switches, U/Man, US 1, "Soft
Attack", term.P M
"Programmed Minus"
(PM) for U/Man
envelope
37 W green Programming, P R 1, plug 2, pin 14 Switches "Wersivoice" and "Pedals"; S 1 PM for control
switches
"Wersivoice/Pedals"
38 not used
39a W green Programming, P R 1, plug 2, pin 13 Push button switches " Reverb, etc.", U S
2, plug 1, pin 1
PM for switches "
Reverb/Vibrato"
39b W green Switches " Reverb,etc.'; US 2, pin PM Push button switches "Piano"; U S 2, plug
1, pin 1
P M for switches
"Piano"
40 W green Programming, P R 1, plug 2, pin 12 Spec. effects, E F 1, plug 3, pin 22 IPM) PM for spec. effects
41 W green Programming, P R 1, plug 2, pin 12 Fixed stops, U/M an, G P 1, plug 2, pin PM PM for fixed stops U/
M an
42 W green Programming, P R 1, plug 2, pin 11 Fixed stops, L/M an, G P 1, plug 2, pin P M P M for fixed stops
L/M an
43 W green Programming, P R 1, plug 2, pin 11 Tab switches "S peedshift,etc."; Z S 1, pin
P M
PM for additional
Wersivoice controls
44 not used
45 not used
46 W black Power suppIy,PS 1, G N D Tone generator, G 1, plug B, pin 8 Ground
47 W black Power supply, PS 1, G N D Piano, PI 1, plug 3, pin GND Ground
48 W black Power suppIy,PS1,G N D Keyers,V 1, term. GN D Ground
49 W black Power supply, PS 1, G N D Wersivoice, WV 7, pin 9 (G N D) Ground
50 W black Power supply, PS 1, G N D Pedal electronics, P E 13, plug 7, pin GND Ground
51 W black Power supply, PS 1, G N D Preamps, V V 2, plug 5, pin G Ground
52 W black Power suppIy,PS 1,G N D Key contacts, L/Man,H K 13,term.G N D Ground
53 W black Power supply, PS 1, G N D Program switches, SP 1, term. G N D Ground
