Wire Material/Color Starts at: Ends at: Purpose, Remarks
W = stranded
wire
(Subunit, PC Board, Terminal) (Subunit, PC Board, Terminal)
S = shielded
cable
54 W black Power suppIy,PS 1,G N D Wah wah control, term.E Ground
55 W black Power suppIy,PS 1, G N D Transposer,TP, point "M" Ground
56 W black Power suppIy,PS1,G N D Slalom control, term.A Ground
57 W black Power suppIy,PS 1,G N D Piano, P113,term.G N D Ground
58 W black Power suppIy,PS 1,G N D Envelope control, U/Man,H K 13,term.G N
D
Ground
59 W black Power supply, PS 1, G N D AP 1, master pitch control, term. E Ground
60 W black Power supply, PS 1, G N D Programming, P R 1, plug 2, pin 20 Ground
61a W black Power suppIy,PS 1, G N D C-bar of shelf (solder lug) Ground
61b W black C-bar of shelf (solder lug) Stop board (solder lug) Ground
62 W black Power supply, PS 1, G N D Ground plane of master control see Fig. 52
63 W black Power suppIy,PS 1,G N D Drawbars U/Man + L/Man (solder lug) Ground
64 W black Power supply, PS 1, G N D Drawbars (Perc.) (solder lug) Ground
65 W black Power supply, PS 1, G N D Spec. effects, E F 1, plug 3, pin 21 Ground
66 W black Power supply, PS 1, G N D Fixed stops, U/M an, G P 1, plug 2, pin G N
D
Ground
67 W black Power supply, PS 1, G N D Fixed stops, L/M an, G P 1, plug 2, pin G N
D
Ground
68 W black Power supply, PS 1, G N D Pream ps, V V 1, plug 1, pin G Ground
69 not used
70 not used
71 W yellow Switches " R everb '; V S 2, plug 1, pin 6 Tone generator, G 1, plug A, pin 7 Delayed vibrato
72 W brown Switches " Reverb '; V S 2, plug 1, pin 7 Tone generator, G 1, plug A, pin 6 Continuous vibrato
73 W pink Switches " Reverb '; VS 2, plug 1, pin 8 Tone generator, G 1, plug A, pin 3 Slow vibrato
74 W white Switches " Reverb '; VS 2, plug 1, pin 9 Tone generator, G 1, plug A, pin 2 Vibrato II
AM 071 (Part)
17
