Wire Material/Color Starts at: Ends at: Purpose, Remarks
W = stranded
wire
(Subunit, PC Board, Terminal) (Subunit, PC Board, Terminal)
S = shielded
cable
75 L gray Switches " Reverb '; V S 2, plug 1, pin
10
Tone generator, G 1, plug A, pin 1 Vibrato III
76 L red/blue Switches " Reverb '; VS 2, plug 1, pin 11 Tone generator, G 1, plug B, pin 2 utoglide on
77a L wh/yel Slalom control, term. S Tone generator, G 1, plug B, pin 3 Autoglide spread
77b L wh/yel Switches " Reverb ...'; V S 2, plug 1, pin
12
Autoglide speed control, term. S Autoglide up/down j
78 L gn/blk Tone generator, G 1, plug B, pin 4 Solder lug strip (W 1 S) AP
2,connector"Swellpedal';term.6(W 1T)
Foot switch for Hawaii
effect
79 W wh/brn Tone generator, G 1, plug B, pin 6 A P 1, master pitch control, term. S (center)
80 W yel/blk Tone generator, G 1, plug B, pin 7 Transpose r, TP, point B 7
81 W wh/blk Transposer, TP, point S --Slalo m control, term. S
82 L wh/blue Tone generator, G 1, plug B, pin 1 A utoglide speed control, term. A (front)
83a L yel/blue Tone generator, G 1, plug A, pin 5 Piano, PI 1,plug 1, pin Trig. "Key down" for
generator
83b L y el/blue Piano, PI 1, plug 1, pin Trig. Spec. effects, E F 1, plug 1, pin 1 "Key down" for piano
83c L yel/blue Spec. effects, plug 1, pin 1 Envelope control, U/Man, H K 13, term.
Pere.
"Key down" for special
effects
84 S blue Piano, PI 1, plug 1, pin 2 (shield to pin G
N D)
Piano, PI 13, term. OUT (shield cut off)
85 S white Piano, PI 1, plug 1, pin 3 (shield to pin G
N D)
Piano, PI 12, 2nd oct.,term. OUT (shield
cut off)
86 S red Piano, PI 1, plug 1, pin 4 (shield to pin G
N D)
Piano, PI 12, 3rd oct.,term. OUT (shield cut
off)
87 S gray Piano, PI 1, plug 1, pin 5 (shield to pin G
N D)
Piano, PI 12, 4th oct.,term. OUT (shield cut
off)
88 W yellow Piano, PI 1, plug 1, pin SPEED Tremolo speed control, term. S
