Wire Material/Color Starts at: Ends at: Purpose, Remarks
W = stranded
wire
(Subunit, PC Board, Terminal) (Subunit, PC Board, Terminal)
S = shielded
cable
89 W yellow Piano, PI 1, plug 1, pin SPEED Tremolo speed control, term. A 88 and 89 are
interchangeable
90 W brown Piano, PI 1, plug 2, pin Ki. Switches "Piano"; U S 2, plug 1, pin 9 Control for Kinura
91 W red/blue Piano, PI 1, plug 2, pin Hs. Switches " Piano'; U S 2, plug 1, pin 12 Control for
Harpsichord
92 W pink Piano, PI 1, plug 2, pin Ho. Switches "Piano"; U S 2, plug 1, pin 11 Control for Honky-
Tonk
93 W white Piano, PI 1, plug 2, pin Ce. Switches "Piano"; U S 2, plug 1, pin 8 Control for Celeste
94 W gray Piano, PI 1, plug 2, pin Pi. Switches "Piano"; US 2, plug 1, pin 10 Control for Piano
95 W yel/red Piano, PI 1, plug 2, pin Ba. Switches "Piano"; U S 2, plug 1, pin 7 Control for Banjo
96 W grn/brn Piano, PI 1, plug 2, pin B. Piano, PI 13, term. B
97 W wh/yel Piano, PI 1, plug 2, pin Ec. Switches "Piano"; U S 2, plug 1, pin 2 Control for Echo
98 W wh/brn Piano, PI 1, plug 2, pin Tr. Switches "Piano", U S 2, plug 1, pin 3 Control for Tremolo
99 W wh/blk Piano, PI 1, plug 2, pin S/L Switches "Piano"; U S 2, plug 1, pin 6 Control for Sustain
100 W wh/red Piano, PI 1, plug 2, pin A Piano, PI 13, term. A
101 W grn/red Piano, PI 1, plug 2, pin Pe. Solder lug strip (W 1 S) AP 2, connector
"Swell pedal"; pin 5 (W 1 T)
Foot switch for piano
sustain
102 S brown Piano, PI 1, plug 3, pin OUT (shield to
pin G N D)
Volume control "Piano", term. E (front) Audio output of piano
103 W yellow Wersivoice,V11V 7, pin 12 Switches, S 1,term. 7 Wersivoice "Heavy"
104 W brown Wersivoice, WV 7, pin 13 Switches, S 1,term. 8 Wersivoice "Soft"
105 W pink Wersivoice, WV 7, pin 14 Switches, S 1,term. 5 Wersivoice "Chorale/F
ast"
106 W white Wersivoice, WV 7, pin 15 Switches, S 1,term. 6 Wersivoice
"Whirl/Choir"
107 W gray Wersivoice, WV 7, pin 16 Tab switch "Speedshift"; ZS 1, plug 1, pin 3
AM 071 (Part)
