Wersi ORION W1S User Manual

Wire Material/Color Starts at: Ends at: Purpose, Remarks
W = stranded
wire
(Subunit, PC Board, Terminal) (Subunit, PC Board, Terminal)
S = shielded
cable
108 W red/blue Wersivoice, WV 7, pin 1c Fixed stops L/Man, G P 1, plug 1, pin FR-
WV
"Fixed Stops to
Wersivoice"
109 W yel/red Wersivoice, WV 7, pin 2c Fixed stops L/Man, G P 1, plug 1, pin SIN-
WV
"Drawbarsto
Wersivoice"
110 W wh/yel Wersivoice, WV 7, pin 3c Fixed stops U/Man, G P 1, plug 1, pin FR-
WV
"Fixed Stops to
Wersivoice"
111 W wh/brn Wersivoice, WV 7, pin 4c Fixed stops U/Man, G P 1, plug 1, pin SIN-
WV
" Drawbarsto
Wersivoice"
112 W wh/red Wersivoice, WV 7, pin 5c Tab switch "Spec. Eff.to Wersivoice"; ZS 1,
plug 1, pin 4
"Spec. Eff.to
Wersivoice"
113 W wh/blue Wersivoice, WV 7, pin 6c Tab switch "Pedals to Wersivoice"; ZS 1,
plug 1, pin 6
"Pedals to Wersivoice"
114 W wh/grn Wersivoice, WV 7, pin 7c Push button "Piano to Wersivoice"; U S 2,
plug 1, pin 5
"Piano to Wersivoice"
115 S yellow Wersivoice, WV 7, pin 10 (OUT) (shield
to pin 9 G N D)
Preamp, V V 2, plug 3, pin E 10 (shield cut
off)
Audio output of
Wersivoice
116 S green Wersivoice, WV 7, pin 1 (shield cut off) Volume control L/M an,term. S (shield to
term. A) (rear)
Audio from L/Man
fixed stops to
Wersivoice
117 S black Wersivoice, WV 7, pin 2 (shield cut off) Drawbars L/Man, term. 13 (shield to term.
151
Audio from L/Man
drawbars to
Wersivoice
118 S gray Wersivoice, WV 7, pin 3 (shield cut off) Volume control U/ Man,term. S (shield to
term. A) (rear)
Audio from U /Man
fixed stops to
Wersivoice
119 S blue Wersivoice, WV 7, pin 4 (shield cut off) Drawbars U/Man, term. 14 (shield to term.
16)
Audio from U /Man
fixed stops to
Wersivoice
AM 071 (Part)
20
