Wersi ORION W1S User Manual

Wire Material/Color Starts at: Ends at: Purpose, Remarks
W = stranded
wire
(Subunit, PC Board, Terminal) (Subunit, PC Board, Terminal)
S = shielded
cable
120 S white Wersivoice, WV 7, pin 5 (shield cut off) Volume control Spec. eff.term. S (shield to
term. A) (rear)
Audio from Spec. eff.
to Wersivoice
121 S red Wersivoice, WV 7, pin 6 (shield cut off) Pedal electronics, P E 13, plug 6, pin 17
(shield to pin 16)
Audio from pedals to
Wersivoice
122 S brown Wersivoice, WV 7, pin 7 (shield cut off) Volume control Piano, term. S (shield to
term. A) (rear)
Audio from piano to
Wersivoice
123 S red Pedal electronics, P E 13, plug 6, pin 9
(shield cut off)
Drawbar "Bass Guitar" in series with 10
kOhms to term. S (shield to term. A) (rear)
Bass guitar volume
124 S white Pedal electronics, P E 13, plug 6, pin 10
(shield cut off)
Drawbar " Fixed Stops'; in series with 22 k
Ohms to term. S (shield to term. A) (rear)
Volume control for
Tuba, Trumpet,
Stringbass
125 W white Pedal electronics, P E 13, plug 6, pin 11 Drawbar " 16 ";in series with 100 k Ohms to
term. S
Volume control for 16'
pedal flute
126 W Way Pedal electronics, P E 13, plug 6, pin 12 Drawbar " 8'n in series with 100 k Ohms to
term. S
Volume control for 8'
pedal flute
127 S gray Pedal electronics, P E 13, plug 6, pin 18
(shield cut off)
Drawbar " 16 ";term. E (front) shield to
term. A (rear.)
128 S red Pedal electronics, P E 13, plug 6, pin 17
(shield to pin 16)
Prea mp, VV 2, plug 3, pin E 6 (shield cut
off)
Audio from pedals to
pream p
129a W blue Pedal electronics, P E 13, plug 5, pin 1 Pedal electronics, P E 13, plug 5, pin 2 Jumper
129b W blue Pedal electronics, P E 13,
plug 5, pin 2
Pedal electronics, P E 13,
plug 5, pin 3
Jumper
129c W blue Pedal electronics, P E 1 3, plug 5, pin 3 Pedal electronics, P E 13, plug 5, pin 6 Jumper
130 W wh/yel Pedal electronics, P E 1 3, plug 5, pin 4 Rocker switch "Sustain" ; S 1,term. 1 Control for long
sustain
131 W wh/brn Pedal electronics, P E 1 3, plug 5, pin 5 Rocker switch "Trumpet"; S 1,term. 2 Control for Trumpet
AM 071 (Part)
21
