Wire Material/Color Starts at: Ends at: Purpose, Remarks
W = stranded
wire
(Subunit, PC Board, Terminal) (Subunit, PC Board, Terminal)
S = shielded
cable
132 W wh/blue Pedal electronics, P E 1 3, plug 5, pin 7 Rocker switch "Stringbass" S 1,term. 3 Control for Stringbass
133 W yel/brn Pedal electronics, P E 1 3, plug 5, pin 8 Rocker switch "Tuba" ; S 1,term. 4 Control for Tuba
134 W yellow Preamp, VV 2, plug 4, pin S 1 Fixed stops L/Man, plug 1, pin FR-VV "Fixed stops to
preamp"
135 W brown Preamp, VV 2, plug 4, pin S 2 Fixed stops L/Man, plug 1, pin SIN-VV "Drawbars to preamp "
136 W wh/red Preamp, VV 2, plug 4, pin S 3 Fixed stops U/Man, plug 1, pin FR-VV "Fixed stops to
preamp"
137 W wh/blue Preamp, VV 2, plug 4, pin S 4 Fixed stops U/Man, plug 1, pin SIN-VV "Drawbars to preamp "
138 W wh/yel Preamp, VV 2, plug 4, pin S 5 Tab switch "Spec.
Eff.to Wersivoice" ZS 1, plug 1, pin 5
"Spec. eff.to preamp "
139 W wh/brn Prea mp, V V 2, plug 4, pin S 6 Tab switch "Pedals to Wersivoice" ZS 1,
plug 1, pin 7
"Pedals to pream p"
140 W wh/red Prea mp, V V 2, plug 4, pin S 11 Switches "Piano"; US 2, plug 1, pin 4 "Piano to pream p"
141 W pink Prea mp, VV 2, plug 5, pin R 1 Switches " Reverb '; US 2, plug 1, pin 2 " Reverb I"
142 W white Preamp, V V 2, plug 5, pin R 2 Switches " Reverb '; U S 2, plug 1, pin 3 " Reverb II"
143 S white Pream p, V V 1, plug 1, pin E 13 (shield
to pin G)
A P 1,audio connector, term.3 (shield to
term. 2)
"Tape Playback"
144 S gray Preamp, V V 1, plug 1, pin A 13 (shield
to pin G)
A P 1, audio connector, term. 5 (shield to
term. 2)
"Tape Record"
145 S red Preamp, V V 1, plug 1, pin F 1 (shield to
pin G )
Reverb springs "Input" (Phono plug) Audio to reverb
springs
146 S green Preamp, V V 1, plug 1, pin F 2 (shield to
pin G )
Reverb springs "Output" (Phono plug) Audio from reverb
springs
147 S green Preamp, V V 2, plug 3, pin E 1 (shield
cut off)
Volume control " L/Man"term. S (shield to
term. A) (rear)
Audio from fixed stops
L/Man to preamp
AM 071 (Part)
22
