TECHNICAL DATA
Type WS8910(89-designation of machinery, representative of Laser)
Measurement accuracy 1.5 mm (≤1m)
Measuring range 0.03-40m
Min display unit 1 mm
Measuring unit M/ ft / in
Laser class II
Laser type 620-680nm, <1 mW
Continuous distance measurement Support
Area measurement Support
Volume measurement
Support
Pythagorean measurement Support
Plus/ minus measurement on area/
volume/ Pythagorean
Support
Min and max Measurement value Support
Data storage 20 groups
Measuring reference switch Support
Lighting on display screen Support
Buzzer Support
Battery type AAA size alkaline battery 1.5Vx2
Operation temperature 0 °C-40 °C
Operation humidity RH<80% (20 °C)
Storage temperature -20 °C-60 °C
Auto laser off 60 seconds
Auto instrument off 300 seconds
Dimension 120mm*50mm*25mm
weight 0.1kg
