Weslo Cadence 620 WETL20000 User Manual

PART LISTÑModel No. WETL20000 R0800A
Key No. Qty. Description
1 1 Console
2 1 Speed Control
3 1 Key/Clip
4 1 Console Plate
5 12 Screw
6 1 Right Handrail
7 1 Left Handrail
8 1 Battery Cover
9 3 Console Bolt
10 2 Frame Pivot Bolt
11 4 Washer
12 4 Handrail Bolt
13 2 Frame Spacer
14 2 Wheel Bolt
15 2 Wheel
16 2 Base Cap
17 5 Handrail Nut
18 1 Handrail Grommet
19 4 Base Pad
20 1 Choke
21 1 Incline Warning Decal
22 1 Wire Harness
23 1 Hood
24 8 Hood Screw
25 1 Belly Pan
26 18 Small Screw
27 2 Belt Guide
28 2 Roller Spacer
29 2 Hood Anchor
30 3 Nylon Washer
31 2 Hood Bracket
32 1 Controller Bracket
33 3 Tie Holder
34 4 Plastic Stand-off
35 1 Controller
36 1 Motor Bolt
37 1 Fan
38 1 Motor Tension Nut
39 1 Star Washer
40 1 Motor Tension Washer
41 7 Wire Tie Screw
42 5 Motor Nut/Frame Pivot Nut
43* 1 Motor Assembly
44 1 Pulley/Flywheel
45 1 Motor
46 1 Reed Switch
47 4 Wire Tie Clamp
48 1 Reed Switch Clip
49 1 Magnet
Key No. Qty. Description
50 1 Belt
51 1 Right Roller Adj. Bolt
52 6 Platform Screw
53 1 Front Roller/Pulley
54 2 Grip Tape
55 1 Frame
56 1 Walking Belt
57 1 Walking Platform
58 2 Incline Leg Bolt
59 1 Ground Screw
60 1 Ground Wire
61 8 8Ó Cable Tie
62 4 4Ó Cable Tie
63 2 Incline Leg
64 2 1 1/2Ó x 3Ó Plate
65 1 Incline Leg Crossbar
66 2 Roller Adj. Washer
67 2 Frame Endcap
68 1 Motor Pivot Bushing
69 1 Roller Tension Bolt
70 1 Roller Tension Nut
71 1 Roller Tension Spring
72 1 Rear Roller
73 1 Releasable Wire Tie
74 1 Allen Wrench
75 1 Latch Warning Decal
76 1 Receptacle
77 1 Storage Latch
78 1 Latch Pin
79 2 Cage Nut
80 1 Base
81 1 Power Cord Set
82 1 Circuit Breaker
83 1 Filter
84 1 Wheel Nut
85 4 Handrail Washer
# 1 8Ó White Wire, 2/Female
# 1 4Ó Black Wire, Male/Flag
# 1 4Ó Black Wire, 2F
# 1 4Ó Black Wire, 2M
# 1 4Ó Green Wire, Ring/Flag
# 1 8Ó Green Wire, Ring/Flag
# 1 4Ó Blue Wire, Male/Flag
# 1 8Ó Black Wire, 2 Flag
# 1 UserÕs Manual
* Includes all parts shown in the box
# These parts are not illustrated
34
REMOVE THIS EXPLODED DRAWING
AND PART LIST FROM THE MANUAL.
Save this page for future reference.
Note: Specifications are subject to change without notice. For information about
ordering replacement parts, see the back cover of the UserÕs Manual.

Weslo Cadence 620 WETL20000 Specifications

General

Brand	Weslo
Model	Cadence 620 WETL20000
Category	Treadmill
Language	English
