Weslo Cadence A 45 Treadmill User Manual

PART LIST—Model No. WETL17105.0 R0107B
Key No. Qty. Description
1 1 Console
2 4 Round Endcap
3 1 Key/Clip
4 1 Console Back
5 4 Electronics Screw
6 1 Right Handrail
7 1 Left Handrail
8 5 Hood Screw
9 2 Motor Tension Bolt
10 2 Frame Bolt
11 2 Rear Roller Bracket Screw
12 4 Handrail Bolt
13 2 Frame Spacer
14 2 Wheel Bolt
15 2 Wheel
16 1 Right Rear Roller Bracket
17 6 Nut
18 1 Belly Pan Grommet
19 6 Base Pad
20 7 13mm Screw
21 1 Latch Warning Decal
22 1 Wire Harness
23 1 Hood
24 1 Left Rear Roller Bracket
25 1 Belly Pan
26 4 Belt Guide Screw
27 2 Belt Guide
28 1 6mm Hex Key
29 1 4mm Hex Key
30 6 Handrail Washer
31 2 Platform Bolt, Front
32 1 Controller Bracket
33 1 Front Roller Star Washer
34 1 Front Roller Adj. Bolt
35 1 Controller
36
1 Motor Bolt
37
1 Left Foot Rail
38 2
Motor Tension Nut
39
1
Motor Star Washer
40 2 Outlet Plate Screw
41
1
Storage Latch Assembly
42
6
Base Pad Screw
43 1 Drive Motor Assembly
44
1 Power Cord
45 6
Bracket Star Washer
46 1 Reed Switch
47 2 Platform Bolt, Rear
48
1
Reed Switch Clip
49
1
Magnet
50 1 Motor Belt
51
2 Rear Roller Adj. Bolt
52
10
Foot Rail Screw
53 1 Front Roller/Pulley
Key No. Qty. Description
54 1 Right Foot Rail
55 1 Frame
56 1 Walking Belt
57 1 Walking Platform
58 2 Motor Bushing
59 2 Motor Bolt
60 2 Handrail Star Washer
61 4 8” Cable Tie
62 1 Motor Isolator
63 2 Incline Leg
64 2 Incline Pin
65 1 Ground Wire
66 1 Filter
67 2 Frame Endcap
68 2 U-nut
69 2 Cushion Fastener
70 4 Console Screw
71 1 Base
72 1 Rear Roller
73 2 Outlet Plate Washer
74 5 M4 Nut
75 4 Platform Nut/Incline Leg Nut
76 2 Platform Cushion
77 2 Front Isolator
78 1 Catch
79 1 Motor Bracket
80 1 Transformer
81 6 Plastic Tie
82 3 Controller Bolt/Ground Bolt
83 2 Incline Leg Bolt
84 1 Motor Pivot Nut
85 4 Incline Leg Washer
86 2 Rear Roller Star Washer
87 6 16mm Screw
88 1 Outlet Bracket Assembly
89
1 Circuit Breaker
90
1 On/Off Switch
91 5
Hood Clip
92
1
Grommet
93 6 Bracket Screw
94
7
M4.2 Screw
#
2
8” White Wire, 2 Female
# 1 4” Black Wire, Male/Female
#
1 8” Green/Yellow Wire, F/Ring
#
1
4” Green/Yellow Wire, F/Ring
# 1 4” Red Wire, M/F
# 1 10” Blue Wire, 2F
#
1
4” Blue Wire, 2F
#
1
User’s Manual
“#” indicates a non-illustrated part.
Specifications are subject to change without notice.
