9
6. Start an M8 x 15mm Bolt (8) with an M8 Star
W
asher (5) into each Upright (53, 54). Then,
firmly tighten all six M8 x 15mm Bolts (8).
6
8
8
8
5
8
5
54
53
7. Attach the Latch Housing (48) to the Left Upright
(53) with two M4.2 x 18mm Screws (58); start
both Screws, and then tighten them.
58
48
53
7
8. Make sure that all parts are properly tightened before you use the treadmill. Keep the included hex keys
in a secure place. One of the hex keys is used to adjust the walking belt (see page 17). To protect the floor or
carpet, place a mat under the treadmill.
