Weslo Elliptical Glider 2.0 User Manual

5
PART IDENTIFICATION CHART
Use the chart below to identify the small parts used in
assembly. The number in parenthesis below each part
refers to the key number of the part, from the PART
LIST on page 14. The number after the dash indicates
the quantity needed for assembly. Note: Some parts
may have been pre-attached for shipping. If a part
is not in the parts bag, check to see if it has been
pre-attached.
M8 x 19mm
Button Screw (10)–2
M8 x 63mm Carriage Bolt (49)–4
M5 x 30mm
Button Bolt (51)–4
M8 x 38mm Button Bolt (53)–2
M4 x 12mm
Button Screw (57)–4
M5 Nylon
Locknut (52)–4
M8 Nylon
Locknut (50)–8
1/2” Nylon
Locknut (35)–2
M8 x 60mm Bolt (56)–2
Pivot Washer (54)–2
Pedal Washer (32)–2
M4 x 19mm Flange
Screw (55)–6
Note: Extra parts may be included.
