MAINTENANCE AND TROUBLESHOOTING
HOW TO MAINTAIN THE EXERCISE BIKE
Inspect and tighten all parts of the exercise bike regu-
larly. Replace any worn parts immediately.
To clean the exercise bike, use a damp cloth and a
small amount of mild detergent.
HOW TO ADJUST THE CHAIN
The chain on the exercise bike should be kept properly
adjusted. If the chain causes excessive noise or slips
as you pedal, the chain should be adjusted.
To tighten the
chain, first loosen
the M10 Flange
Nut (53) on each
side of the exercise
bike. Next, loosen
the M8 Nut (56) on
each side of the
exercise bike.
To tighten the
chain, turn the M8
x 50mm Button Bolt
(46) on each side
of the exercise bike
clockwise; to loosen
the chain, turn
the Button Bolts
counterclockwise.
Make sure that the
Flywheel (15) is straight.
See the drawing at the left. When the chain is prop-
erly tightened, tighten the M8 Nuts (56). Then, tighten
the M10 Flange Nuts (53).
53
56
46
15
