8
4. Attach the Hood (9) to the front of the Frame
(10) with four M4 x 12mm Screws (4); start all
four Screws, and then tighten them.
5. Hold the front of the Frame (10) between the Left
and Right Handrails (5, 7).
The Frame (10) can be inclined at two levels.
Align the hole in the Frame with one of the holes
in the Right Handrail (7). Then, tighten a Knob
(11) into each Handrail and into the Frame.
Make sure that both Knobs are at the same
level.
4
4
9
10
4
11
11
5
10
7
5
3. Raise the Right Handrail (7) and the Left
Handrail (5) to the position shown.
3
5
7
