9
7. Connect the Reed Switch Wire (14) to the
Lower Handrail Wire (8). Then, clip the Upright
Grommet (15) onto the Reed Switch Wire, and
press the Upright Grommet into the Left Upright
(5).
14
8
15
5
6. Insert the Pin (12) into the holes in the Right
Handrail (7) and the Frame (10). Make sure that
the Pin is fully inserted. Then, attach a Spring
Clip (13) to the end of the Pin.
IMPORTANT: Make sure that the Pin (12) is
fully inserted and that the Spring Clip (13) is
attached when the treadmill is being used.
10
12
13
7
6
7
