SERVICE BULLETIN V.31
DATE:
1/23/85
BULLETIN
NUMBER:
148
MODEL:
ALL
PROPULSION
ENGINES
SUBJECT:
FIELD
TROUBLESHOOTING
TACHOMETER/HOURMETER
PN
11917
The
tachometer/hourmeter
used
in propulsion engine instrument panels contains
two
separate
electrical
circuits
with a
common
ground.
One
circuit
operates
the hourmeter,
and
the other the tachometer.
The
hourmeter
circuit
operates
on
12
volts/alternator
charging voltage supplied to the (+) terminal
on
the
back
of the instrument.
The
tachometer
circuit
operates
on
AC
voltage
6-8
volts,
fed
from
one
of the
diodes
in
the
alternator
and
supplied to the "tach
inp.1I
terminal while the
engine
,is
running,
and
the
alternator
producing battery charging voltage
13.0-14.8 volts
D.C.
'
The
following are procedures to follow
when
troubleshooting a
fault
in
either
of the
two
circuits
in the tachometer/hourmeter.
HOURMETER
FAULT
1. Inoperative
TACHOMETER
FAULT
1. Inoperative
PIN:
34791
CHECK
1.
Check
for proper
DC
voltage
between
(+)
and
(-)
terminals.
A.
Voltage present - meter defective - repair
or replace.
B.
Voltage
not
present - trace (+)
and
(-)
electrical
connections for
fault.
(Jump
12
Volts
DC
to meter (+) terminal to
verify operation.)
CHECK
1.
Check
for proper
AC
voltage
between
"Tach
Inp.1I
terminal
and,
(-)
terminal
with
engine running.
A.
Voltage present - attempt adjusting meter
through calibration access hole.
No
results,
repair or replace meter.
B.
AC
voltage not present -
check
for proper
alternator
D.C.
output voltage.
C.
Check
for
A.C.
voltage
at
tach terminal
on
alternator
to ground.
D.
Check
electrical
connectio'ns
from
"tach
Inp."
terminal to
alternator
connection.
