TERMINALS
12
English
TERMINALS
Item Function
1. DC in
Connects the AC adapter from this outlet to a
power source.
2. TV tuner
Connects the LED TV to an antenna or cable
service.
3. Composite AV input
Connect to an external AV device such as a VCR,
DVD player, set-top box, or game system.
4. Audio in Connects to the audio out port of a computer.
5. VGA
Connects to a computer or other device with a
VGA output using a 15-pin VGA cable.
6. Audio out
Connect to an audio output device.
7. SPDIF audio out Connects to an external digital audio receiver.
8. HDMI 1/2
Connects to an external AV device such as a
VCR, DVD player, set-top box, or game system.
9. USB Service port For service only.
SPDIF
L
-
RY
-
L
-
R VGAAUDIO INTUNERDC IN
HDMI 1
HDMI 2
USB
1 2 4 5
7
9
8
