SPECIFICATIONS
61
English
SPECIFICATIONS
Item Specification
Model Name LD-325 Series
Panel
Active Area
(Diagonal, mm)
697.685 (H) x 392.256 (V)
Resolution 1366 (H) x 768 (V)
Brightness
(Nits, typ)
250
Contrast Ratio
(min)
3000:1
Response Time
(min)
6.5ms(g-g)
Aspect Ratio 1.77 (16:9)
Display color 16.7M
Audio/Video
Input/Output
Terminals
•HDMI x2
• AV with R/L Audio x1
• VGA with 3.5 mm mini jack x1
• SPDIF Out x1
• USB for service x1
• Tuner x1
• R/L Audio Line Out X1
Speaker Out 10W (2 channels)
AV Timing 480i/p, 720p, 1080i/p
PC Timing
640 x 400 @ 85Hz,
640 x 480 @ 60Hz/75Hz,
800 x 600 @ 56Hz/60Hz/75Hz,
1024 x 768 @ 60Hz/70Hz/75Hz/85Hz,
1280 x 768 @ 60Hz,
1360 x 768 @ 60Hz,
1440 x 900 @ 60Hz,
1366 x 768 @ 60Hz
Power Consumption
(Watts)
≤ 90W
