39
INSTALLATION
Please follow the points below when installing your appliance:
USE AN AUTHORISED PERSON
As stated in the local municipal building codes and other relevant statutory regulations.
• Wiring connections must be in accordance with AS/NZS 3000 Wiring Rules and any particular
conditions of the local authority.
• Refer to data plate for rating information and circuit diagram. The data plate is positioned
behind the bottom of the oven door. The circuit diagram is positioned on the top panel of the
appliance.
• A functional switch should be provided near the appliance in an accessible position. Refer to
AS/NZS 3000 clause 4.3.11
• Wiring should be protected against mechanical failure. Refer to AS/NZS 3000 clause 3.9
• A means of disconnection with a contact separation of at least 3mm must be supplied in the
fixed wiring.
• To gain access to the mains connection terminals, remove the rear panel by unscrewing the 2
assembly screws.
NOTE: Where connection is made to a multi-phase 240V supply, the bridge piece should be
removed from between the active connections.
IMPORTANT: This appliance must be properly earthed.
• Do not lift the appliance by the door handles.
• Prepare the cupboard opening to match your appliance measurements. (See diagrams).
• Slide appliance into the cupboard, ensuring that the supply cable (where fitted) and the flexible
gas hose (where fitted) does not kink.
• To prevent tipping, use the screws supplied to secure your oven into the cupboard by fastening
through the 2 holes (underbench) or 4 holes (separate grill) to the front panel.
• For appliances fitted with a supply flexible cord, if the cord is damaged, it must be replaced by
the manufacturer or its service agent or similarly qualified person in order to avoid a hazard.
The plug must be accessible after installation.
• Where the appliance is built into a cabinet, the cabinet material must be capable of
withstanding 85°C. Installation into low temperature tolerant cabinetry (e.g. vinyl coated) may
result in deterioration of the low temperature coating by discolouring or bubbling.
• If the appliance is installed adjacent to vinyl-wrapped surfaces, use an installation kit available
from the vinyl-wrap supplier.
• Electrolux Home Products cannot accept responsibility for damage caused by installation into
low temperature tolerant cabinets.
• After installation, test and ensure that the appliance operates correctly before handing it over
to the customer.
IMPORTANT: Before you cook in your new oven:
• Make sure that the room is well ventilated (to allow smoke to escape).
• It may take several hours to totally eliminate the smell of the adhesive used in the insulation.
It is best to initially operate the oven with windows and doors open for 4-8 hours.
CAUTION: To avoid any potential hazard, you must follow our instructions below when
you install your appliance. Failure to install the appliance correctly could invalidate any
warranty or liability claims and lead to prosecution.
