Westinghouse WHE7670SA - Care and Cleaning

8 care & cleaning
CARE & CLEANING
2
1
4
3
5
6
7
1. Water Dispenser
• Removethestrainerandcleanthewatercollectingtray
with a sponge or absorbent cloth.
9
2. Ice cubes storage case
• Removing:Pressthereleasebuttonandremovetheice
cube container.
• Cleaning:Emptytheicecubecontainerandclean
with tepid water. Thoroughly dry the container
and screw conveyor to prevent new ice cubes
from sticking.
• Replacing:Pushtheicecubecontaineralltheway
back onto the supports until it locks into position.
If the container cannot be pushed all the way back,
rotate the swirl coil a quarter turn and insert again.
9
3. Freezer & Refrigerator Bins
• Holdbothendsandpullup.
9
4. Refrigerator Shelves
• Liftupandpulltheshelf,unhookandthenremovethe
shelf.Youcanreplaceitatvaryingheights.
• Toplacetalleritemssuchastallbottles,youcan
remove the small glass shelf and place it in the holder
under the icemaker.
9
