12 13CONTROLS
1. Hotplate Control Knobs
Adjusts temperature of hotplate. Can be rotated in
either direction.
2. Hotplate Indicator Lamp
Comes on when you turn a hotplate on.
3. Temperature Control Knob
Sets temperature for baking.
4. Oven Indicator Lamp
Indicator lamp lights up when the oven element
is heating. It will cycle on and off to maintain the
required temperature in the oven.
5. Function Switch
Sets oven functions.
Bake - with light
Grill - with light
Light - light only
CONTROLS
WLE620WC
WLE624WC
1. Hotplate Control Knobs
Adjusts temperature of hotplate. Can be rotated
in either direction.
2. Hotplate Indicator Lamp
Comes on when you turn a hotplate on.
3. Temperature Control Knob
Sets temperature for baking.
4. Oven Indicator Lamp
Indicator lamp lights up when the oven element
is heating. It will cycle on and off to maintain the
required temperature in the oven.
1
3 5
42
5. Function Switch
Sets oven functions.
Bake - with light
Grill - with light
Light - light only
6. Timer
Sets reminder time.
7. General Purpose Outlet Switch
1
3 5
6
7
42
7
INSTALLATION
INSTALLATION
Fitting the grill dish supports
• Insert the rear hook into the rear hole.
• Align the front peg to the front hole and push
in firmly.
Fitting the grill dish
Separate grill
Ensure rear of the dish is engaged with the side support
before sliding backwards. To remove, simply pull forwards
and upwards.
Engagement of
rear dish
Grill in oven
(Refer to Fitting Oven Shelves)
The grill dish with wire insert can be used in any of the
two upper height positions (shelf positions 4 and 5)
between the runners.
NOTE: You must remove the grill dish when baking in
the oven.
Grill dish
insertion
Grill dish
final position
