Construction and Features
704 67 020 00 _ 111
GF Robimat XL / XM
OPERATING INSTRUCTIONS

1
2
3
4
5
6
7
8
9
10
11
12
1 Product container
2 POS (Point of Sale)
3 Sliding door unit
4 Display
5 Coin insert
6 Selection keypad
7 Product delivery unit (delivery unit ap,
shutter)
8 Chiller unit
9 Coin return
10 Product basket
11 Vertical track
12 Glass door


