Machine control board, Software
704 67 020 00 _ 111
GF Robimat XL / XM
OPERATING INSTRUCTIONS
In the [SERVICE MODE] menu all important machine parameters are displayed. This menu provides support for
locating errors and machine maintenance.
Various functions can be tested and the coin mechanism emptied.
Service numbers are divided into categories, M, double M, and L functions.
Number Display Comments
101 - 103M empty single coins from the tubes of a 3-tube
coin changer
If coins remain in the tubes, they must be
emptied via the service keypad on the coin
mechanism. The information about which coin
is assigned to which tube is shown by the
manufacturer on the identication plate on the
coin mechanism.
105 - 109M remove single coins from the tubes of a 4- or
5-tube coin changer
111 - 113M remove all coins from the tubes of a 3-tube
coin changer
115 - 113M empty all coins from the tubes of a 4- or 5-tube
coin changer
201M Check chiller unit ATTENTION: Do not carry out this test several
times in succession, because the compressor
will no longer start against the pressure
build-up.
202M Check heater
203M Check illumination
204M Check evaporator fan
1L Processor voltage display
5L Check temperature and temperature sensor If a temperature of 99°C is displayed, the
sensor or the lead from the control board is
faulty. The reason could be a short-circuit or
break.
21L Software version display
22L Control board run-time display
24L The compressor run time is displayed in hours
and minutes
29L Display shows password entered
91L Display shows all active MDB-equipment
99M55M Patch Menu
99M57M All products are sold in accordance with age
verication for the minimum age of 16 years.
This function depends on the document reader
in use.
99M58M All products are sold in accordance with age
verication for the minimum age of 18 years.
99M59M All products are sold without age verication.
99M81M Generates a data reset ATTENTION Clear this manually caused error
and re-programme the control board.
99M91M Restore to factory settings Same as data error 81, but the serial ash
is also deleted. This means all changes on
the machine are reset, including patches
and manual ash backups. Only the patches
and default values set in the software at the
factory, including customer specic settings will
remain.
