Machine control board, Software
704 67 020 00 _ 111
OPERATING INSTRUCTIONSGF Robimat XL / XM
[MACHINE NUMBER]
[ 0 ] to [ 9 ] The number assigned by the factory may be replaced by an internal number selected by the
customer as part of an in-house control system. The serial number is located on the machine
identication plate.
[PCB-
SERIALNUMBER]
PCB = Printed Circuit Board
- The circuit board serial number is displayed. You are unable to make any changes here.
[SECURITY DEF.
CODE A]
[SECURITY DEF.
CODE B]
Managing the access to menus / access rights; password protection
[DEF. CODE A:]
[DEF. CODE B:]
In order to avoid unauthorised programming, the menus can
be assigned a locking code. The locking codes are structured
hierarchically.
[CODE A] provides the lowest access level. It unlocks the
[COOLING], [TEST VENDS] [SHOW STATISTICS] and [SHOW
FULL STAT] menus. Code A is intended for the machine ller.
[Code B] unlocks the [PROGRAMMING MODE], [SHOW FULL
STAT], [PROG.TIME/LOCKS], [INSTALLING MODE] and
[SERVICE MODE] menus.
If you enter [CODE B], even if [CODE A] is requested, all menus
can be accessed. The security codes can be freely selected
from 0 to 9999.
If [CODE A] is installed, [CODE B] has to also be installed. Both
codes can be the same.
A menu locked using [CODE A] or [CODE B] requires the
relevant code to be entered to obtain access. The digits are not
displayed. After entering the code, press [ E ] to conrm!
USER 4
----
SECURITY
DEF. CODE A: 0
CODE A
----
CODE B
----
Security code is set here
USER 4
----
SPERRCODE
CODE A WIRD: 0
CODE A
----
CODE B
----
Code A must be entered
USER 4
----
SPERRCODE
CODE A WIRD: 0
CODE A
----
CODE B
----
Code B must be entered
[VARIANT (1)] Setting the machine type.
[FS40] (default) [FS40] relates to Robimat XL, XM.
SECURITY
DEF.CODE B: 0
this is where the password is entered, i. e. programmed.
[FREE VEND MO. (1)] To programme free vend mode for time-restricted dispense of products.
[FREE VEND DURAT.] To programme the time for goods to be dispensed once the free vend code has been
entered.
[FREE VEND CODE] Four digit code to activate the Free Vend Time.
[EXT. SERIAL 5.2] Programme machine data read out function.
[HMI] Read out using HMI-protocol
[READOUT] Read out using downloading devices.
[MACHINE NUMBER]
[ 0 ] to [ 9 ] The number assigned by the factory may be replaced by an internal number selected by the
customer as part of an in-house control system.
