Westomatic ELEVATE QUARTZ - 7.3 Machines centre of gravity

68
Transportation, Storage, Decommissioning, Disposal
704 67 020 00 _ 111
GF Robimat XL / XM
OPERATING INSTRUCTIONS
Reinforcement
Cut-out showing the base of the machine
The forklift forks must be placed under the complete machine base.
The base of the vending machine comprises two reinforcing plates to provide the necessary stability.
View from below
