GF Robimat XL / XM
OPERATING INSTRUCTIONS




1 = clean
2 = test/ check
3 = lubricate
4 = replace/ exchange
OK
12 Months or
30,000
1)
24 Months or
60,000
1)
36 Months or
90000
1)
LED functioning
2 2 2
Folding mechanism, light strip left
2 2 2
Cable routing top left
2 2 2




1 = clean
2 = test/ check
3 = lubricate
4 = replace/ exchange
OK
12 Months or
30,000
1)
24 Months or
60,000
1)
36 Months or
90000
1)
Vending machine control board M32:
Backup battery minimum 2.8V
Voltmeter 2 2 2
Coin chutes Rinsing water
1+2 1+2 1+2
Selection keypad, external Rinsing water
1+2 1+2 1+2
Display Rinsing water
1 1 1
Coin return tray Rinsing water
1 1 1
Coin return motor - check if
working
2 2 2
Coin mechanism, card reader,
banknote reader
Cleaning according
to manufacturer’s
specications
- - -
Product to collection unit
Internal area
1 1 1
Smooth operation of locking slide
including spring
2 2 2
Delivery unit ap
Even motorised travel
movable by hand 2 2 2
Lifting capacity at least 250 g
e. g. 0.25l can
2 2 2
Sliding clutch function
e. g. 0.25l can
2 2 2




1 = clean
2 = test/ check
3 = lubricate
4 = replace/ exchange
OK
12 Months or
30,000
1)
24 Months or
60,000
1)
36 Months or
90000
1)
Product container locking function 2 2 2
Internal area of product container
2)
Check if clean and clean if
required
1+2 1+2 1+2

movable with even force
2 2 2
Latch mechanism of pusher/slide 2 2 2
Position of the belt in the pusher 2 2 2
Positioning of belt deector at the
rear
3 3
Damage to toothed belt 2 2 2
