GF Robimat XL / XM
OPERATING INSTRUCTIONS
1 = clean
2 = test/ check
3 = lubricate
4 = replace/ exchange
OK
12 Months or
30,000
1)
24 Months or
60,000
1)
36 Months or
90,000
1)
Upper part of basket Rinsing water
1 1 1
Light grid Brush, air
1 1 1
Light grid:
Flashing mode at 5 second
intervals?
2 2 2
Damage on drive belt
2 2 2
Damage to gear wheel pendulum
2 2 2
Pendulum gear wheel assembly
Multi-function lubricant
Berulub FR 43
998 90 064 00
3 3 3
Uniform power transmission when
the pendulum is swung to and fro
2 2 2
Damage to pendulum hook
2 2 2
Bearing for pendulum hook
Special lubricant
e. g. Microlube GL 261
part no. 998 90 037 01
3 3 3
Gear motor, upper shaft bearing
Special lubricant
e. g. Microlube GL 261
part no. 998 90 037 01
3 3 3
1 = clean
2 = test/ check
3 = lubricate
4 = replace/ exchange
OK
6 Months
3)
12 months
3)
18 Moths
3)
Test key T on the FI-circuit
breaker
press
2 2 2
1 = clean
2 = test / check
3 = lubricate
4 = replace/ exchange
OK
12 Months or
30,000
1)
24 Months or
60,000
1)
36 Months or
90000
1)
Start positions for selections
10, 18, 30, 38, 50, 58:
X-direction: Toothed wheel for
pendulum drive aligned with toothed
wheel of product compartment
Y-direction: Pendulum hook catches
in the centre at the hook-in position
on the product container
2 2 2
1) whichever occurs rst.
2) The condition of the container surface plays an important part in the correct functioning of the machine. Products with
sticky, sugary contents also often tend to be soiled on the outside. Drink residue on bottles soils the product containers and
prevents the bottles from moving smoothly.
The condition of the product container surface must be recorded and, if it is not clean, a complaint must be led with the
operator!
3) Attention, interval changed (every six months)
