A
B
(4)
-beeep-
MAX MIN / OFF
MOTOR
JIGGING
Automatic winding with electric power and how to cahnge speed
The speed control by the motion of motor and speed lever
„JIGGING“ switch, Jigging funktion
(1) Push the „JIGGING“ button and the electric motor winds up the line
as long as you push the switch.
To stop the motors release the button.
For Jigging (fast moving of the bait)
you can push an d release the button intervallic.
Speed control with the Speed Lever (Powerslider)
(2) To start the motor and to increase the speed stepless, you have to push the Powerslider to direction “MAX“.
(3) To decrease the speed stepless, you have to pull the Powerslider to direction “MIN“.
When the Powerslider reaches the block at “MIN“, the motor will stop.
(4) You also can stop the motor without vary the position of the Powerslider by pushing the „JIGGING“ switch.
To start the motor again, you optionally can use the jigging funktion,
or pull the Powerslider down to “MIN“ (4A), wait for the beep signal
and than push the Powerslider again to direction “MAX“ (4B).
In the folowing cases the motor stops automatically, respectively can´t be activated by pushing “ON/OFF/JIGGING“ button :
(a) if the line actually is spooled up to the saved “water surface 0“ position.
(b) if the line actually is spooled up to the saved “sides of boat“ position.
(c) in case none of those positions is saved, the motor stops 5 meter before the end of line and also can´t be activated with
the “ON/OFF/JIGGING“. The rest of the shing line must be spooled up manually with the handle.
15
