(1) Connect the shing line to the spool by passing level wind and connect
the reel to electrical power supply. It displays like picture (1).
(2) Push the “SET“ switch and the “MODE“ switch coincidently for 3 seconds.
It displays like picture (2).
(3) Now wind up the line with the electric motor power
by pushing the speed lever foreward.
(4) If the required length of line is on the spool, push the “MODE“ switch
for saving the line datas. The display shows like picture (3).
(3)
NOTE : - If inadvertently the „SET“ switch is pushed while winding up the line,
all line datas will be lost, so you have to repeat the procedure.
- According to strain of line and / or expansion, error of indication about 5% are possible.
9
