Whale SL5512 - Page 6

Icon Description Icon Description
0.75kW Electric Off 0.75kW Electric On
1.50kW Electric Off 1.50kW Electric On
3.00kW Electric Off 3.00kW Electric On
Gas Off Gas On
Fan Off Fan On
Off Button Active Off Button Inactive
Night Mode (10
o
C - 18
o
C) Off
Night Mode (10
o
C - 18
o
C) Active
Night Mode Selected
Frost Protection Mode (6
o
C - 10
o
C)
Off
Frost Protection Mode (6
o
C - 10
o
C)
Active
Frost Protection Mode Selected
Increase Temperature Button
Decrease Temperature Button
Figure 3. Room Heater Control Screen
