whaler 220 Dauntless - Trailer Description

2-24 220 Dauntless
Section 2 • General Information
R
Bunk Trailer (Typical)
Fig. 2.24.1
TIRES
SPARE TIRE
WINCH SAFETY CHAIN
KEEL PROTECTOR
AXLES
SAFETY CHAINS
TONGUE/BALL HITCH RECIEVER
TRAILER LIGHT CONNECTION, (4-PIN)
TONGUE JACK
WINCH STAND/ASSEMBLY
CABLE ROLLER
WINCH HOOK/STRAP
TRAILER FRAME
SIDE LIGHT
FENDER W/ STEPS
TAILLIGHT (HIDDEN)
TIE-DOWN EYE
BUNK ASSEMBLY
3
4
2
1
6
7
8
9
11
12
14
15
13
5
16
17
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
11
12
9
18
10
9
NEVER use a hitchball and coupler that are not
matched.
!
CAUTION
DO NOT secure the chains to the bumper of the
tow vehicle.
!
CAUTION
Trailer description
