4-4 220 Dauntless
Section 4 Electrical System
R
The following pages contain electrical schematics
pertaining to the electrical system in your boat. These
schematics were generated by technicians in the
Boston Whaler
®
Engineering Department and are for
reference and to be used by service technicians.
Boston Whaler
®
does not recommend that you
attempt to work on the electrical system yourself.
Instead, we suggest that you take your boat to an
authorized Boston Whaler
®
dealer for electrical
service.
Electrical Schematics & Harnesses
Wiring Identification Chart
Boston Whaler
®
adheres to electrical wiring
requirements which meet all the ABYC-11 standards.
The chart below outlines the gauge, color and
function of the wiring used.
Boston Whaler
®
reserves the right to change or update
the electrical system on any model at any time
without notice to the customer and is not obligated
to make any updates to units built prior to the change.
GAUGE COLOR FUNCTION
6 AWG GRN GROUNDING MAIN/TOWER &
ALUMINUM FUEL TANKS
8 AWG GRN GROUNDING
8 AWG ORN STARBOARD 30 AMP
RECEPTACLE
8 AWG RED MAIN FEEDS/PORT 30 AMP
RECEPTACLE
12 AWG BRN/BLK STARBOARD FISHBOX PUMP
12 AWG BRN/VIO FORWARD FISHBOX PUMP
12 AWG BRN/YEL LIVEWELL PUMP
(HIGH CURRENT)
12 AWG BRN/BLU PORT FISHBOX PUMP
12 AWG BLK GROUND
12 AWG RED +12V MAIN
14 AWG BLK GROUND
14 AWG BLK/YEL STOP CIRCUIT
14 AWG BLK/WHT GEN SHUTDOWN
14 AWG BLU COMPASS
14 AWG BLU/BLK DOME LIGHT
14 AWG BLU/GRN SPREADER LIGHT
14 AWG BLU/ORN LIVEWELL LIGHT
14 AWG BLU/RED COURTESY LIGHTS
14 AWG BLU/VIO CABIN LIGHTS
14 AWG BRN BILGE PUMP (SWITCHED)
14 AWG BRN/BLK STARBOARD FISHBOX PUMP
14 AWG BRN/BLU PORT FISHBOX PUMP
14 AWG BRN/GRY RAW WATER
14 AWG BRN/GRN FRESH WATER
14 AWG BRN/ORN SUMP PUMP
14 AWG BRN/RED BILGE PUMP (UNSWITCHED)
14 AWG BRN/VIO FORWARD FISHBOX PUMP
14 AWG BRN/WHT MACERATOR
14 AWG BRN/YEL LIVEWELL PUMP
14 AWG GRY RUNNING LIGHTS
14 AWG GRY/BLK ACC 1
14 AWG GRY/BLU ACC 2
14 AWG GRY/GRN ACC 3
14 AWG GRY/RED AFT MAST/ACC 4
14 AWG GRY/WHT ALL ROUND/FWD MAST LIGHT
14 AWG GRN GROUNDING
14 AWG ORN REFRIGERATOR or CENTER
WIPER
14 AWG ORN/BLU HORN
14 AWG ORN/BRN STARBOARD WIPER PARK
14 AWG ORN/GRN STARBOARD WIPER
14 AWG ORN/RED PORT WIPER
14 AWG ORN/VIO VACUUM PUMP
14 AWG ORN/WHT CENTER WIPER
14 AWG PINK FUEL SENDER
14 AWG RED 12V RECEPTACLE
14 AWG VIO IGNITION
14 AWG WHT CO MONITOR/ELECTRIC TRIM
TAB (SWITCHED)
14 AWG YLW BLOWER/STEREO MEMORY
14 AWG YLW/RED START
GAUGE COLOR FUNCTION
Wire Color Chart for DC and Special Circuit
