P83159 B
Sheet 5 of 6
APPLICATION NOTES:
CAUTION: If sheated multiconductor cable or 3/4" conduit fittings are used, check that installed product has sufficient clearance
and wiring room prior to installing backboxes and conduit.
1. For weather resistant installation, use outdoor mounting option. Outdoor backbox must be mounted vertically with “TOP” as
marked to allow any moisture or condensation to drain properly through drain holes on bottom of backbox.
2. 115VAC Multitone Appliances can be surface mounted to a standard 4 inch square by 2-1/8 inch deep electrical box (Figure A)
or a weather resistant backbox (WBB) (Figure B).
3. Select largest backbox shown in Mounting Options where possible, to provide additional wiring room for easy installation.
4. Conduit entrance to backboxes should be selected to insure sufficient wiring clearance for installed equipment. When extension
rings are required, conduit should enter through backbox, not extension ring. Use Steel City #53151/1-1/2" deep or #53171/2-
1/8" deep extension rings or equal with same area cut out in back.
5. Use care and proper techniques to position the field wires in the backbox so that they use minimum space and produce minimum
stress on the product. This is especially important for stiff, heavy gauge wires with thick insulation or sheathing.
6. Do not pass additional wires (used for other than signaling appliances) through the backbox. Such additional wires could result
in insufficient wiring space for the signaling appliance.
7. The Code-3 Horn and Code-3 Tone incorporate the temporal pattern specified by ANSI/NFPA/ISO for standard emergency
evacuation signaling. They should be used only for fire evacuation signaling and not for any other purpose.
8. The Horn and Bell Tones can be used on coded systems with a minimum On-Time of 1/4 second. All other tones are
recommended for use only on continuous (non-coded) systems.
The Multitone products and these instructions are copyrighted by Wheelock and contain proprietary, confidential and trade secrets of
Wheelock. No part of the Multitone products and these instructions may be photocopied, printed or reproduced in any form or
modified, adapted, changed or enhanced, or converted to another programming language, or used to create updated, related or
derivative works, without the prior written consent of Wheelock. No part of the Multitone shall be decompiled, disassembled or
reverse engineered.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the
FCC Rules. These limits are designed to provide reasonable protection against harmful interference in residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
1) Reorient or relocate the receiving antenna, 2) Increase the separation between the equipment and receiver, 3) Connect the
equipment into an outlet on a circuit different from that to which the receiver is connected, and 4) Consult the dealer or an
experienced radio/TV technician for help.
ANY MATERIAL EXTRAPOLATED FROM THIS DOCUMENT OR FROM WHEELOCK MANUALS OR OTHER
DOCUMENTS DESCRIBING THE PRODUCT FOR USE IN PROMOTIONAL OR ADVERTISING CLAIMS, OR FOR
ANY OTHER USE, INCLUDING DESCRIPTION OF THE PRODUCT'S APPLICATION, OPERATION, INSTALLATION
AND TESTING IS USED AT THE SOLE RISK OF THE USER AND WHEELOCK WILL NOT HAVE ANY LIABILITY
FOR SUCH USE.
IMPORTANT: READ SEPARATE "GENERAL INFORMATION" SHEET FOR INFORMATION ON THE
PLACEMENT, LIMITATIONS, INSTALLATION, FINAL CHECKOUT AND PERIODIC TESTING OF NOTIFICATION
APPLIANCES.
