SERVICE
01.06.2007 / Page 4 AWE 4017 Whirlpool Europe
Doc. No: 4812 722 28036 8593 401 42070 Customer Service
Spare part list
Model AWE 4017
Service No. 859340142070
Version 859340142070
Pos. No. 12NC Code Description
002 0 4812 459 38057 Flap round GW
002 1 4812 459 38058 Hinge flap GW
004 0 4812 440 19625 Drip tray assy
010 0 4812 459 48175 Door frame inner GW
010 1 4812 440 11637 Frame Top+nozzle box KIT
011 0 4812 462 48054 Foot
012 7 4812 310 18497 Trolley kit front
012 8 4812 528 78075 Foot rear
021 0 4812 440 10838 Front panel WH GW
022 0 4812 440 10839 Side panel right GW
022 1 4812 440 10841 Side panel left GW
024 0 4812 440 11638 Rear panel
040 0 4812 417 19155 Hinge bolt lid GW
061 0 4812 466 88995 Counter weight rear, 5 pts
061 1 4812 466 88996 Counter weight front
061 2 4812 466 88492 Counter weight bottom
081 4 4812 529 18043 Shock absorber
086 4 4812 529 18045 Pin f. Shock absorber
086 5 4812 529 18052 Damper f. Shock absorber
100 1 4812 440 10842 Lid outer GW
100 3 4812 440 10843 Lid inner GW
100 5 4812 440 10845 Lid assembly WH GW
110 4 4812 498 18249 Handle cpl. WH GW
130 0 4812 417 19193 Door latch GW
191 0 4812 466 68596 Door bellow
191 1 4812 492 98037 Strap f. bellow
200 0 4812 418 18633 Tub LR 5pts/T20-40
200 1 4812 418 18634 Tub LR 5 pts/20-40WELDED
201 0 4812 440 11679 Cover for tub ALL/T20-40
220 0 4812 418 18635 Drum LR 05-06/SO 6/7 NIT
223 0 4812 418 48725 Drum lifter
271 0 4812 358 18167 Belt Poly V 1204 H8 MA
272 0 4812 528 88083 Pulley 298 mm
290 0 4812 532 68078 Gasket
301 0 4812 453 10434 Control panel AWE 4017
331 0 4812 414 58306 Knob timer EBL WP25
331 2 4812 414 58307 Knob timer ring, bush spring
332 0 4812 410 29501 Push button 4-opt.
333 0 4812 410 29503 Push button start/reset
400 0 4812 361 58444 Motor 1BA5736-0WA/BSH
421 0 4812 121 18285 Interf.filter 1,00 µ F
421 2 4812 404 38679 Holder RFI
430 0 4812 360 18577 Pump,draining
451 0 4812 259 28919 Heating element 2050W, 230V+ NTC
490 0 4812 321 18311 Cable mains ISRAELE
490 1 4812 321 28367 Strain relief
521 0 4812 214 70092 Control unit DOMINO, basic
521 0 4812 214 70331 Control unit DOMINO, programmed
571 0 4812 281 28468 Valve magnet
571 1 4812 281 18069 Cover for top frame
581 0 4812 271 28585 Pressostat 50/25 INVENS.
620 0 4812 239 58046 Module E3/4 Opt.
630 0 4812 271 38519 Door lock 3P ROLD
653 0 4812 134 18079 Light guide PR.FLOW-START/RST
653 1 4812 134 18081 Light guide 4 OPTIONS-noRPM
Pos. No. 12NC Code Description
691 0 4812 282 19485 Sensor NTC SC1,OMEGA3
701 0 4812 530 29329 Hose inlet EN 11770 Reflex
702 2 4812 530 29453 Hose valve-dispenser
707 0 4812 526 48242 Nozzle box cold cpl.
707 1 4812 526 48049 Clamp f. nozzle box
712 4 4812 418 68302 Siphon f. softener
712 6 4812 418 68164 Clip SOAP DISPENSER
712 9 4812 418 68404 Soap dispenser cpl. 3 ch.
753 0 4812 418 68187 Chamber,air
754 0 4812 530 28938 Drainhose
754 1 4812 530 28832 Lock eco
760 0 4812 480 58089 Filter set pump
781 0 4819 530 29035 Hose draining
782 0 4812 530 28941 Hose Pressostat
787 0 4812 530 29309 Hose Air Exaust
787 1 4812 530 29311 Cover of hose
794 0 4812 530 58098 Gasket Airtrap
900 0 4819 401 18686 Clamp hose
900 1 4812 401 18431 Clamp to pump
900 2 4812 255 18304 Hose Holder
900 3 4819 401 18529 Clamp hose
901 0 4812 401 18462 Clamp hose drain hose
910 0 4812 502 48347 Screw,selftap 3,5x14SS
910 1 4812 502 38151 Screw 4x14
910 3 4812 502 18404 Screw
910 4 4812 502 18423 Screw PT 7x15
910 5 4812 502 18705 Screw M8x35
910 6 4812 502 18399 Nut Push in M 8
921 0 4812 400 18047 Washer
930 1 4812 492 48171 Torsions spring
930 2 4812 492 48162 Spring
941 0 4812 310 19144 Bearing kit ALL 1100
953 0 4812 325 68001 Shaft seal
962 0 4812 440 98142 Cover for Motor AC
962 2 4812 440 11424 Spacer
965 0 4812 462 79974 Cap Transport blocking
990 0 4812 310 18504 Fixing mat.set front counter
990 2 4812 310 18506 Fixing mat.set bottom
993 0 4819 530 29028 Bow
993 1 4812 290 18025 Clamp heatingelement
