TESTING
Whirlpool 2014 CABRIO
®
Direct Drive Washer
n
6-7
For Service Technician Use Only
TEST #2 Valves
This test checks the electrical connecons to the valves, and
the valves themselves.
1. Check the relays and electrical connecons to the valves
by performing the Cold, Hot, Oxi (not on all models), and
Fabric Soener Service Test Load Control on page 5-5.
Each test acvates and deacvates the selected valve. The
following steps assume one (or more) valve(s) did not turn
on.
2. For the valve(s) in queson check the individual solenoid
valves:
a. Unplug washer or disconnect power.
b. Remove console to access main control.
c. Remove connector J2 from main control. Refer to main
control diagram on page 6-6.
d. Check harness connecon to solenoid valves.
3. Check resistance of the valve coils across the following J2
connector pinouts:
Valve Pinout
Fabric Soener J2, 4 & 7
OXI (not on all models) J2, 4 & 8
Hot J2, 4 & 9
Cold J2, 4 & 10
Resistance should be 790–840 Ω.
¾ If resistance readings are tens of ohms outside of
range, replace the valve assembly.
¾ If resistance readings are within range, replace main
control and perform Service Diagnoscs to verify
repair.
L1
MAIN BOARD
N
790 - 840
WATER INLET VALVES
SOFTENER (4)
J12-1
J2-8
BK
R
V
OR
BU
W
W
MAIN BOARD
J12-3
J2-7
J2-10
J2-9
J2-4
BLEACH/OXI (1)
MAIN HOT (2)
MAIN COLD (3)
W
W
W
W
Figure 1
Figure 2
HotCold
Softener (4)
Main Cold (3) Main Hot (2)
Bleach/Oxi (1)
WARNING
Electrical Shock Hazard
Disconnect power before servicing.
Failure to do so can result in death or
electrical shock.
Replace all parts and panels before operating.
To Next Page
