Whirlpool FL 5085 - Motor and Control Systems

SERVICE
Whirlpool Europe FL 5085 11.11.2002 / Page 3
Customer Service 8570 508 10050 Doc. No: 4812 712 17681
Technical data
Drain pump (synchronous)
Nominal Voltage 230 V
Nominal/max. current 0.3/0.5 A
Nominal power 35 W
Frequency 50 Hz
Resistor (coil) (20 ˚C) 162 Ω
Motor protection Thermal-fuse
Capacity (0.55 - 1.0 m) 20 ± 2 l/min
Position of draining hose
outlet min. 0.55 m
max. 1.0 m
Program timer
Type SC1 - 3330
Timer basic 4619 710 67586
Timer programmed 4619 753 00211
Nominal voltage 230 V
Frequency 50 Hz
Program
Positions 32
Motor
Type MCA 45/64 - 148/
TAT 1
Belt ratio i = 1:15.91
Resistance contacts (20 ˚C)
Stator (full field) 2.07 Ω ± 7%
Stator (tapped field) 1.32 Ω ± 7%
Rotor 2.00 Ω ± 7%
Tachogenerator 67.80 Ω ± 7%
Input power (at 230 V AC)
Washing 250 W ± 7%
Rinsing 310 W ± 7%
Spinning 380 W ± 10%
Radio interference supression
Rated voltage 90 - 250 V
Rated current 16 A
Frequency 50/60 Hz
Nominal capacity 470 nF X1 + 2 x 22 nF Y
Main switch
Type 1DLF1006
Nominal voltage 250 V
Nominal current 16 (5) A
Poles 2
Functionality Normally opened
Connection in RAST 5 6.3 pins
Connection lamp 2.8 pins
Pilot lamp
Nominal voltage 230 V
Option switch
Nominal voltage 5 V DC
Nominal current 1 mA
Poles 1
Functionality Normally opened
Connection RAST 2.5
Temperature/spin speed selector
Positions 7
Nominal voltage 5 V DC
Nominal current 1 mA
Poles 1
Connection RAST 2.5
Value of resistors ± 5%:
5 - 6 Position 1 <10 Ω
Position 2 0.68 kΩ
Position 3 1.10 kΩ
Position 4 1.80 kΩ
Position 5 2.70 kΩ
Position 6 3.60 kΩ
Position 7 4.70 kΩ
Push button switch
ON/OFF SM
Rapid OPT. 1
Rinse intensive OPT. 2
Rinse stop OPT. 3
Cotton-/
coloured
Easy
care
Deli-
cate
Wool Silk
Pre wash 02 - 06 03 - 06 04 - 06 - -
Main wash 07 - 21 12 - 21 14 - 21 17 - 21 18 - 21
Rinse 22 - 28 22 - 28 22 - 28 22 - 28 22 - 28
Spin 29 - 31 29 - 31 29 - 31 29 - 31 29 - 31
Stop 32 32 32 32 32
