SERVICE
11.11.2002 / Page 4 FL 5085 Whirlpool Europe
Doc. No: 4812 712 17681 8570 508 10050 Customer Service
Spare part list
Model FL 5085
Service No. 857050810050
Version 857050810050
Pos. No. 12NC Code Description
001 0 4812 440 10328 Cabinet + feet TATRY
011 0 4812 462 48077 Foot adjustable
013 0 4812 462 48078 Foot fix
021 0 4812 440 19481 Front,panel
024 0 4819 440 19897 Panel, rear
025 0 4812 404 38636 Support control board VBL
025 1 4812 452 19849 Holder Frontpanel
030 0 4812 440 10481 Table top WH VBL
034 2 4819 492 68458 Fastener
034 3 4819 532 68243 Bushing
040 0 4819 417 19232 Hinge
053 0 4819 440 19901 Plinth
061 0 4819 466 89453 Counter weight ,top
061 1 4819 466 89454 Counter weight ,bottom
080 0 4812 492 38386 Spring,suspens.
081 0 4812 466 48093 Friction plate
083 1 4819 462 38925 Friction plate
084 0 4819 462 48049 Silent bloc
086 0 4819 401 18607 Clamp bushing
110 0 4819 498 78444 Handle
130 0 4819 417 38117 Lock
130 1 4819 535 38062 Shaft Hooh
141 0 4819 450 69519 Door glass
143 0 4812 440 10652 Door cpl. WH VBL
143 1 4812 440 10483 Glassdoor frame WH VBL
144 0 4819 532 28288 Frame,door glas
144 1 4819 466 89077 Plate door frame
190 0 4819 468 18344 Door bellow
190 1 4819 492 38119 Strap porthole seal
190 2 4819 492 68515 Strap porthole seal
200 0 4812 418 18411 Tub
201 0 4812 464 48165 Bottom Tub cpl.
201 1 4819 532 88052 Ring
201 2 4812 464 48166 Bottom Tub
210 0 4812 535 78064 Crosspiece,drum
220 0 4812 418 18412 Drum
220 1 4812 418 18413 Drum cpl.
228 0 4812 418 18212 Plate
271 0 4812 358 18158 Belt
272 0 4812 528 88102 Pulley
292 0 4819 466 69797 Gasket
301 0 4812 452 11711 Control panel FL 5085
331 0 4812 414 58175 Knob,timer VBL
332 0 4812 513 18118 Push button WH VBL
335 0 4812 414 58176 Knob thermostat WH VBL
336 0 4812 414 58178 Knob,potentiom.
339 0 4812 233 18006 Adapter f. Knob
351 0 4812 124 98001 Lamp mains
401 0 4812 361 58358 Motor MCA 45/64, 800
421 0 4812 121 18142 Interf.filter 1,00 µ F
430 0 4812 360 18527 Pump,draining with Protector
451 0 4812 259 28835 Heating element 230 V
490 0 4819 321 18136 Cable,mains 2m SA
491 0 4812 321 28367 Strain relief
502 0 4812 282 19333 Timer SC1 progr. 825 MP 3330
Pos. No. 12NC Code Description
572 0 4812 271 28506 Valve,magnet single
583 0 4812 271 28507 Pressostat
620 3 4819 410 28998 Switch options
621 0 4812 276 18276 Switch ON/OFF
622 0 4812 413 48279 Selector,switch Temp./Spin
630 0 4819 276 18416 Door lock
701 0 4819 530 29034 Hose, inlet
702 0 4812 530 29128 Hose dispenser/valve
707 0 4812 526 48033 Nozzle Distribution 4
707 1 4812 526 48028 Nozzle
708 1 4812 530 48358 Bend dispenser/tub
711 0 4812 418 68245 Detergent disp.
712 0 4812 418 68246 Drawer VBL
713 0 4812 418 88028 Flap Detergent Cont.
717 0 4812 321 38022 Bowden cable
717 1 4812 321 38013 Lever , Nozzle
717 2 4812 321 38012 Holder,adjust.
717 3 4812 278 88018 Slide
717 5 4812 233 18003 Cam 4 C. incl. adapter WH
718 0 4812 526 48051 Siphon
718 1 4812 418 88024 Accessory
753 1 4819 418 68234 Chamber,air
754 0 4819 526 48255 Drainhose inner Tub/Pump
754 1 4812 530 28832 Lock eco
781 0 4819 530 29035 Hose,draining
783 0 4819 530 29036 Hose pressostat
787 0 4812 530 29129 Steam hose
794 5 4812 530 58098 Gasket Airtrap
900 0 4812 255 18205 Holder Pressostat
901 0 4819 401 18529 Clamp,hose
901 1 4819 401 18174 Clamp,hose 25-45 mm
901 2 4812 401 18501 Clamp,hose 19.2 mm
901 3 4819 401 18882 Clamp
901 6 4819 401 18436 Clamp,hose
902 1 4812 255 18204 Holder Hose outlet
910 6 4819 502 38005 Screw
912 2 4819 310 38685 Set screw
914 0 4812 505 18371 Nut M 12
931 0 4819 492 38138 Spring,suspens.
932 0 4819 492 68666 Spring
932 5 4812 492 38359 Spring , Nozzle
941 0 4819 903 00802 Bearing,ball 6204-2ZR
941 1 4812 520 28001 Bearing,ball 6205 2Z C3
951 0 4812 530 58097 Shaft seal 800-1000
990 0 4819 310 39124 Mounting kit ,weight top
990 1 4819 310 38684 Mounting kit ,weight bottom
990 2 4819 310 39099 Accessories CROSSPIECE
